En per stom toeval kwam ik dit tegen. Vorig jaar helemaal gemist.
Secret aerodynamicist over Newey.
Het gaat me om het laatste stuk, namelijk het verschil tussen low en high rake en waar het einde van de vloer voor is.
Het begint al met wat nieuws voor mij. De vloer afsluiten waar het zo vaak om gaat, gaat dus niet om lucht die ontstapt onder de vloer, maar lucht die onder de vloer word getrokken. Daarvoor hadden ze dus die outwash. Dat ging dacht altijd om lucht weg te duwen voor de voorwielen zodat die geen aerodynamische problemen veroorzaken, maar het gaat dus ook om lucht weg te duwen van de vloer. Kennelijk doen de bargeboards dit.
Het doel van de vloer is lucht versnellen omdat dit gepaard gaat met een lagere luchtdruk en dat genereert de gewenste neerwaartse druk. Low rake maakt dat verzegelen in principe simpeler, maar high rake zou beter zijn voor het managen van de luchtstromen rond de achterbanden. De vloer zit immers dichter op de achterwielen over het geheel van een ronde omdat de vloer hoger zit en dus dichterbij het midden van de band. Zo kan je de diffuser ook efficiënter maken wat belangrijk is om de luchtstromen door de diffuser niet te vertragen.
Het is dus niet de een is voordelig, de ander niet. Het is meer een afweging. Maar het verklaard wel wat we in 2018 zagen met de RB14. Betere verwerking van de luchtstromen bij de achterbanden, efficiëntere diffuser, beter bandenmanagement en meer neerwaartse druk. Ja, die blijf ik terughalen want die auto missen we op het moment gewoon. Die werkte vanaf FP1.
Het roept bij mij wel meteen de vraag op wat er gaat gebeuren in 2021 als de hoeken van de vloer eraf moeten van de FIA. Als ik er zo naar kijk, dan zou het Mercedes ook wel eens meer kunnen treffen dan RBR. Het zal denk ik weinig goeds doen voor bandenmanagement voor welk team dan ook, maar ik vraag me nu wel af of het Mercedes niet zwaarder gaat treffen. Immers blijft er nog een stukje van de vloer uitsteken voor de achterbanden. Alle aerodynamische openingen die moesten helpen de vloer af te sluiten, die verdwijnen en ik heb eigenlijk de indruk dat Mercedes daar alsnog meer op ontwikkeld heeft en op inzet dan RBR. Beetje paradoxaal, maar die indruk krijg je wel als je foto's vergelijkt. Ergens vermoed ik dat RBR meer doet met hun bargeboards i.p.v de vloer.
Ik begrijp denk ik nu ook wat ze probeerden met die nieuwe vloer. Lucht naar buiten duwen, weg van de banden.

A few technical extras
For those of you keen for more, read on as we discuss a few of the complexities of airflow with high and low rake.
In practice, one of the most critical things to consider is what is referred to as floor sealing. In my experience this is a bit of a catch-all term for talking about managing the airflow that comes off the sides of the floor, which we might be using to try to do a few different things.
One of these is trying to minimise the amount of air that is drawn under the floor from the sides.
Remember, we would like to accelerate the air under the floor as fast as we can, for as long as possible. To use another analogy, if you think of the airflow as a queue, and the diffuser as a gate through which people can pass at a set rate, you can see that the queue at the front of the floor will travel much faster if people don't keep pushing in from the sides.
Low rake can make this particular problem a little easier, as the smaller gap between the sides of the floor and the ground tends to impede air from going under the car.
On the other hand, high rake can be advantageous in another aspect of floor sealing - managing the rear-tyre wake.
Tyre wake, as we discussed in the last article, is the churning, turbulent air found behind the tyre, which we likened to the water behind a boat. Much like water, tyre wake will spread out behind the body that creates it. This is a problem because it has the effect of blocking the air exiting the diffuser, which we would like to be as large as possible to pull a lot of air under the floor.
In order to control the tyre wake, we try to direct vortices, which are spinning streams of air a bit like a mini tornado, towards the parts of the tyre where the wake is separating.
This encourages the air to stay attached to the tyre longer and results in a smaller wake, which can have a completely transformative effect on the performance of the diffuser.
Components in this area of the car are so sensitive because the small changes to the air around the tyre which they produce can have such big knock-on effects on the tyre wake, and, as a result, on the performance of the diffuser.
We saw this in Australia when what looked like relatively minor damage to the corner of Hamilton's floor had a devastating effect on his race.
At high rake, because the floor is raised up nearer to where the circular tyre face is vertical, a given movement of the wheel up or down won't make the gap between the tyre and floor open up very much.
However, on a low-rake car, the floor sits lower against the tyre face. As the car goes around the track and sees the same movement up or down, the gap between tyre and floor will change much more. This can make the job of tuning the aerodynamic devices harder.
Those are just two examples of a multitude of issues that arise from a team's choice of design concept.
https://www.bbc.com/sport/formula1/47838557
