Mogelijke specs:
SoC (CPU+GPU) Model: GMLX30-R-A1.
Memory Model: MT62F768M64D4EK-026 (6GX2 dual channel, LPDDR5X, 7500 MT/s)
Storage Model: THGJFGT1E45BAILHW0 (256GB, UFS 3.1, Kioxia manufacture, 2100 MB/s).
Audio Chip Model: Realtek ALC5658-CG.
NFC Reader Model: NXP PN7160B1HN.
Internal Microphone Model: CMB-MIC-X7.
Dual Heat Dissipation Fans, Models BSM0405HPJH9 and BSM0505HPJQC (Copper-made game console heat dissipation chip).
Video Signal Conversion (DisplayPort to HDMI) Chip Model: Realtek RTD2175N chip (supports HDMI 2.1).
Network Chip Model: Realtek RTL8153B-VB-CG Gigabit Ethernet chip (dock has wired network port).
Microcontroller Chip Model: STMicroelectronics STM32G0B0CET6.
Video Game Console Protective Shell Model: HGU1100 (Dimensions: 206 × 115 × 14mm, made of plastic).
Speakers: MUSE BOX-L and MUSE BOX-R (dual-channel stereo).
SoC heeft een codenaam, maar is naar alle waarschijnlijkheid (99,9% zeker op dit punt) de T239. Een door Nvidia custom made SoC voor Nintendo, in tegenstelling tot de eerste Switch die een off-the-shelf SoC gebruikte. De vraag is alleen nog of het 8nm of 5nm wordt. Dat tweede is logischer ivm batterijduur en productie, maar het eerste is goedkoper en waarschijnlijk makkelijker in te boeken bij de fabrikant.
En de kloksnelheden:
Quote:
Handheld:
CPU 1100.8 MHz
GPU 561 MHz
EMC 2133 MHz
Docked:
CPU 998.4 MHz
GPU 1007.25 MHz
EMC 3200 MHz
