| return {
on = {
timer = {
"on 06/12-31/12 every 5 minutes between civiltwilightend and 23:59"
}
},
data = {},
logging = {},
execute = function(domoticz, triggeredItem)
local kleuren = { {r=255, g=0, b=0}, {r=255, g=128, b=0}, {r=255, g=255, b=0}, {r=128, g=255, b=0}, {r=0, g=255, b=0}, {r=0, g=255, b=128}, {r=0, g=255, b=255}, {r=0, g=128, b=255}, {r=0, g=0, b=255}, {r=128, g=0, b=255}, {r=255, g=0, b=255}, {r=255, g=0, b=128} }
local devices = { 94, 95, 99 }
local frames = 60;
local function hslToRgb(h, s, l)
h = h / 360
if s == 0 then
l = math.floor((l * 255) + 0.5)
return l, l, l
end
local function to(p, q, t)
if t < 0 then
t = t + 1
end
if t > 1 then
t = t - 1
end
if t < .16667 then
return p + (q - p) * 6 * t
end
if t < .5 then
return q
end
if t < .66667 then
return p + (q - p) * (.66667 - t) * 6
end
return p
end
local q = l < .5 and l * (1 + s) or l + s - l * s
local p = 2 * l - q
return math.floor((to(p, q, h + .33334) * 255) + 0.5), math.floor((to(p, q, h) * 255) + 0.5), math.floor((to(p, q, h - .33334) * 255) + 0.5)
end
local function rgbToHsl(r, g, b)
r = r / 255
g = g / 255
b = b / 255
local max = math.max(r, g, b)
local min = math.min(r, g, b)
local h = (max + min) / 2;
local s, l = h, h
if (max == min) then
h = 0
s = 0 -- achromatic
else
local d = max - min;
if (l > 0.5) then
s = d / (2 - max - min)
else
s = d / (max + min)
end
if (max == r and g < b) then
h = (g - b) / d + 6
elseif (max == r and g >= b) then
h = (g - b) / d
elseif (max == g) then
h = (b - r) / d + 2
elseif (max == b) then
h = (r - g) / d + 4
end
h = h / 6;
end
return (h * 360), s, l;
end
for deviceIndex = 1, #devices do
local rgbDevice = domoticz.devices(devices[deviceIndex])
if (rgbDevice.active == true) then
-- Just a simple rand would somehow always give device #2 & #3 the same color; So enjoy multiple math randoms for each device!
math.randomseed( os.time() * deviceIndex )
local randKleurId = math.random(1,#kleuren)
for frame = 1, deviceIndex do
randKleurId = math.random(1,#kleuren)
end
local currentColor = rgbDevice.getColor()
local currentColorHlsH, currentColorHlsS, currentColorHlsL = rgbToHsl(currentColor.r, currentColor.g, currentColor.b)
local newColor = kleuren[randKleurId]
local newColorHlsH, newColorHlsS, newColorHlsL = rgbToHsl(newColor.r, newColor.g, newColor.b)
-- Decide to turn Hls clockwise or anti-clockwise (and speed)
local hInc = 0;
if ((currentColorHlsH == newColorHlsH or math.abs(currentColorHlsH - newColorHlsH) == 180) and math.random(1,2) == 2) then
hInc = 180 / frames
elseif (currentColorHlsH == newColorHlsH or math.abs(currentColorHlsH - newColorHlsH) == 180) then
hInc = -180 / frames
elseif ((currentColorHlsH + 180 > newColorHlsH and currentColorHlsH < newColorHlsH) or (currentColorHlsH + 180 > 360 and currentColorHlsH - 180 > newColorHlsH)) then
if (currentColorHlsH > newColorHlsH) then
hInc = ((newColorHlsH + 360) - currentColorHlsH) / frames
else
hInc = (newColorHlsH - currentColorHlsH) / frames
end
else
if (currentColorHlsH > newColorHlsH) then
hInc = (newColorHlsH - currentColorHlsH) / frames
else
hInc = (newColorHlsH - (currentColorHlsH + 360)) / frames
end
end
-- Special random full circle to animate from a color to the same color
if (currentColorHlsH == newColorHlsH) then
hInc = hInc * 2
end
if (hInc ~= 0) then
for frame = 1, (frames - 1) do
-- calculate frame hls values
local frameHlsH = currentColorHlsH + (hInc * frame)
if (frameHlsH < 0) then
frameHlsH = frameHlsH + 360
end
if (frameHlsH >= 360) then
frameHlsH = frameHlsH - 360
end
local frameHlsS = currentColorHlsS
if (currentColorHlsS ~= newColorHlsS) then
frameHlsS = (currentColorHlsS - (currentColorHlsS - newColorHlsS) / frames * frame);
end
local frameHlsL = currentColorHlsL
if (currentColorHlsL ~= newColorHlsL) then
frameHlsL = (currentColorHlsL - (currentColorHlsL - newColorHlsL) / frames * frame);
end
-- Calculate frame rgb values
local frameRgbR, frameRgbG, frameRgbB = hslToRgb(frameHlsH, frameHlsS, frameHlsL)
local secs = frame - 1;
if (secs == 0) then
rgbDevice.setColor(frameRgbR, frameRgbG, frameRgbB, rgbDevice.level)
else
rgbDevice.setColor(frameRgbR, frameRgbG, frameRgbB, rgbDevice.level).afterSec(secs)
end
end
-- At end of animation set final select color
rgbDevice.setColor(newColor.r, newColor.g, newColor.b, rgbDevice.level).afterSec((frames - 1))
end
end
end
end
} |
