Leuk dingetje
Linkje met meer info:
https://www.kickstarter.c...f-things-fast/description
Size and Weight
[list]• 40x25x9mm (1.6x1.0x0.4'')
• 14mm (0.6'') width with Bluetooth shield
• Board: 5.7g (0.20oz)
• Battery: 4.0g (0.14oz)
Processor
[list]• ATmega328P processor @ 8MHz
• Pre-loaded standard Arduino Fio bootloader, no custom firmware needed
• 100% Arduino compatible
• Arduino IDE support (any IDE version on OSX/Windows/Linux)
Peripherals and I/Os
[list]• 16-million colors user-defined RGB LED, 2240mcd max, 120° viewing angle
• 7x GPIO, 3x PWM, 2x 10-bit ADC, I2C, SPI solderless proto connector
• Up to 18x GPIOs, 6x 10-bit analog inputs or 6x PWMs
Wireless
[list]• 5-second automatic Over-The-Air Programming
• Supported wireless shields: Bluetooth 2.1 (RN42XVP, RN41XVC), Bluetooth BLE 4.0 (BLE-LINK), WiFi (RN-XV-W), XBee (XB24-API, XBP24-API), SIGFOX (TD1208), GPRS (GPRSbee SIM800H)
Power Management System
[list]• Autonomy in communication: 6 months @ 1 data/minute
• Autonomy in sleep mode: up to 3 years
• Charge time: 40-60 minutes
• 150mAh rechargeable lithium-ion battery
• Built-in lithium-ion battery charger
• Charging via micro USB from computer system or power adapter
• Battery protection circuitry (Over Current, Over Charge, Over Discharge)
• USB voltage, charge status and battery level indicators
• 5VUSB/500mA and 3.3V/200mA regulated power outputs for prototyping board
• 3.3V/1A switchable regulated power output for wireless shield
[
