"config_version": 2,
"homeassistant": {
"ip_address": "supervisor",
"protocol_api": "http"
},
"database_ha": {
"engine": "mysql",
"server": "core-mariadb",
"port": 3306,
"database": "homeassistant",
"username": "homeassistant",
"password": "!secret db_ha_password"
},
"database_da": {
"engine": "mysql",
"database": "day_ahead",
"server": "core-mariadb",
"port": 3306,
"username": "day_ahead",
"password": "!secret db_da_password"
},
"meteoserver_key": "!secret meteoserver-key",
"meteoserver_model": "harmonie",
"meteoserver_attemps": 2,
"prices": {
"source_day_ahead": "nordpool",
"entsoe_api_key": "!secret entsoe-api-key",
"energy_taxes_consumption": {
"2022-01-01": 0.06729,
"2023-01-01": 0.12599,
"2024-01-01": 0.1088,
"2026-01-01": 0.09154
},
"energy_taxes_production": {
"2022-01-01": 0.06729,
"2023-01-01": 0.12599,
"2024-01-01": 0.1088,
"2026-01-01": 0.09154
},
"cost_supplier_consumption": {
"2022-01-01": 0.002,
"2023-03-01": 0.018,
"2024-04-01": 0.0175,
"2026-01-01": 0.0
},
"cost_supplier_production": {
"2022-01-01": 0.002,
"2023-03-01": 0.018,
"2024-04-01": 0.0175,
"2026-01-01": 0.0
},
"vat_consumption": {
"2022-01-01": 21.0,
"2022-07-01": 9.0,
"2023-01-01": 21.0
},
"vat_production": {
"2022-01-01": 21.0,
"2022-07-01": 9.0,
"2023-01-01": 21.0
},
"multiplier_consumption": {
"2000-01-01": 1.0
},
"multiplier_production": {
"2000-01-01": 1.0
},
"last_invoice": "2026-02-01",
"tax_refund": true
},
"logging_level": "info",
"use_calc_baseload": false,
"baseload_calc_periode": 56,
"baseload": [
0.14,
0.38,
0.26,
0.42,
0.25,
0.22,
0.13,
0.25,
0.23,
0.26,
0.31,
0.32,
0.31,
0.23,
0.26,
0.21,
0.21,
0.54,
0.26,
0.26,
0.22,
0.19,
0.18,
0.16
],
"graphical_backend": "",
"graphics": {
"style": "Solarize_Light2",
"battery_balance": true,
"prices_consumption": true,
"prices_production": true,
"prices_spot": true,
"average_consumption": true,
"show": "true"
},
"interval": "15min",
"strategy": "input_select.dao_strategy",
"max_gap": 0.005,
"notifications": {
"notification_entity": "input_text.dao_notificatie",
"opstarten": true,
"berekening": true,
"last_activity_entity": "input_datetime.dao_laatste_activiteit"
},
"grid": {
"max_power": 17.0,
"entity_balance_switch": "input_boolean.dao_balance_switch_eva"
},
"history": {
"save_days": 7
},
"dashboard": {
"port": 5000
},
"battery": [
{
"name": "Zinvolt",
"entity_actual_level": "sensor.evasoc_dao_waarde",
"capacity": 3.0,
"upper_limit": 100,
"lower_limit": 18,
"optimal_lower_level": 18,
"penalty_low_soc": 0.001,
"entity_min_soc_end_opt": "input_number.dao_entity_min_soc_end_eva",
"charge_stages": [
{
"power": 0.0,
"efficiency": 1.0
},
{
"power": 100.0,
"efficiency": 0.85
},
{
"power": 200.0,
"efficiency": 0.88
},
{
"power": 300.0,
"efficiency": 0.9
},
{
"power": 400.0,
"efficiency": 0.91
},
{
"power": 1600.0,
"efficiency": 0.93
},
{
"power": 1800.0,
"efficiency": 0.93
},
{
"power": 2000.0,
"efficiency": 0.95
}
],
"discharge_stages": [
{
"power": 0.0,
"efficiency": 1.0
},
{
"power": 100.0,
"efficiency": 0.92
},
{
"power": 200.0,
"efficiency": 0.93
},
{
"power": 300.0,
"efficiency": 0.94
},
{
"power": 400.0,
"efficiency": 0.94
},
{
"power": 900.0,
"efficiency": 0.95
},
{
"power": 1400.0,
"efficiency": 0.95
},
{
"power": 1600.0,
"efficiency": 0.95
}
],
"reduce_power_low_soc": [],
"reduce_power_high_soc": [],
"minimum_power": 300,
"dc_to_bat_efficiency": 0.95,
"bat_to_dc_efficiency": 0.95,
"cycle_cost": 0.02,
"entity_set_power_feedin": "input_number.dao_feedin_grid",
"entity_set_operating_mode": "input_select.dao_eva_operating_mode",
"entity_set_operating_mode_on": "Aan",
"entity_set_operating_mode_off": "Uit",
"entity_calculated_soc": "input_number.dao_entity_calculated_soc",
"solar": []
}
],
"solar": [
{
"name": "Enphase",
"entity_pv_switch": "input_boolean.solar_pv_on_off",
"tilt": 30.0,
"orientation": -140.0,
"capacity": 11.68,
"yield_factor": 0.0485,
"strings": [],
"ml_prediction": true,
"ml_training_start_date": "2000-01-01",
"entities_sensors": [
"sensor.envoy_totale_energieproductie_kwh"
],
"sensor history": "sensor.envoy_totale_energieproductie_kwh"
}
],
"electric_vehicle": [
{
"name": "Kia Niro EV",
"capacity": 55.0,
"switch_cost": 0.0,
"entity_position": "input_select.kia_locatie_dao",
"charge_three_phase": "True",
"charge_stages": [
{
"ampere": 0.0,
"efficiency": 1.0
},
{
"ampere": 6.0,
"efficiency": 0.8
},
{
"ampere": 7.0,
"efficiency": 0.8
},
{
"ampere": 8.0,
"efficiency": 0.8
},
{
"ampere": 9.0,
"efficiency": 0.8
},
{
"ampere": 10.0,
"efficiency": 0.9
},
{
"ampere": 11.0,
"efficiency": 0.9
},
{
"ampere": 12.0,
"efficiency": 0.9
},
{
"ampere": 13.0,
"efficiency": 0.9
}
],
"entity_actual_level": "input_number.dummy_kia_soc",
"entity_plugged_in": "input_boolean.kia_ingeplugd_dao",
"entity_instant_start": "input_boolean.dao_nu_laden",
"entity_instant_level": "input_number.dao_nu_laden_soc",
"charge_scheduler": {
"entity_set_level": "input_number.gewenst_laadniveau_dao",
"level_margin": 2,
"entity_ready_datetime": "input_datetime.kia_niro_ready_time"
},
"charge_switch": "input_boolean.kia_niro_charge_enable",
"entity_set_charging_ampere": "input_number.kia_niro_set_charging_ampere",
"entity_stop_charging": "input_datetime.stop_laden_ev",
"entity max amperage": "input_number.niro_ac_max_ampere"
}
],
"machines": [
{
"name": "Airco",
"programs": [
{
"name": "Uit",
"power": []
},
{
"name": "Auto",
"power": [
1000.0,
1000.0,
1000.0,
1000.0,
1000.0,
900.0,
900.0,
800.0,
600.0,
400.0
]
}
],
"entity_start_window": "input_datetime.start_window_airco",
"entity_end_window": "input_datetime.eind_window_airco",
"entity_selected_program": "input_select.airco_programma",
"entity_calculated_start": "input_datetime.berekende_start_airco",
"entity_calculated_end": "input_datetime.berekende_stop_airco",
"entity_instant_start": "input_boolean.dao_nu_airco"
},
{
"name": "Afwasmachine",
"programs": [
{
"name": "Uit",
"power": []
},
{
"name": "45-65 Graden",
"power": [
1575.0,
25.0,
30.0,
1870.0,
1000.0,
0.0
]
}
],
"entity_start_window": "input_datetime.start_window_afwasmachine",
"entity_end_window": "input_datetime.eind_window_afwasmachine",
"entity_selected_program": "input_select.afwasmachine_programma",
"entity_calculated_start": "input_datetime.berekende_start_afwasmachine",
"entity_calculated_end": "input_datetime.berekende_stop_afwasmachine",
"entity_instant_start": "input_boolean.dao_nu_afwasmachine"
}
],
"boiler": {
"boiler_present": false,
"entity actual temp.": "sensor.boiler_gemeten",
"entity setpoint": "sensor.boiler_ingesteld",
"entity hysterese": "sensor.hysterese_hot_water",
"cop": 2.9,
"cooling rate": 0.4,
"volume": 180,
"heating allowed below": 44,
"elec. power": 1500,
"activate service": "press",
"activate entity": "input_button.hw_trigger"
},
"heating": {
"heater_present": false,
"degree days factor": 3.6,
"stages": [
{
"max_power": 225,
"cop": 7.1
},
{
"max_power": 300,
"cop": 7.0
},
{
"max_power": 400,
"cop": 6.5
},
{
"max_power": 500,
"cop": 6.0
},
{
"max_power": 600,
"cop": 5.5
},
{
"max_power": 750,
"cop": 5.0
},
{
"max_power": 1000,
"cop": 4.5
},
{
"max_power": 1250,
"cop": 4.0
}
],
"entity adjust heating curve": "input_number.stooklijn_verschuiving_day_ahead",
"adjustment factor": 0.04
},
"tibber": {
"api_token": "!secret tibber_api_token",
"api_url": "https://api.tibber.com/v1-beta/gql"
},
"xgboost": {
"tune_hyperparameters": true
},
"report": {
"entities_grid_consumption": [
"sensor.energie_verbruik_dynamisch_contract"
],
"entities_grid_production": [
"sensor.energie_teruglevering_dynamisch_contract"
],
"entities_solar_production_ac": [
"sensor.envoy_totale_energieproductie_kwh"
],
"entities_solar_production_dc": [],
"entities_ev_consumption": [
"sensor.smartevse_ev_import_active_power_corrected"
],
"entities_wp_consumption": [],
"entities_boiler_consumption": [],
"entities_battery_consumption": [
"sensor.totaal_batterij_consumption_dao"
],
"entities_battery_production": [
"sensor.totaal_batterij_production_dao"
],
"entities_machine_consumption": [],
"entity co2-intensity": [
"sensor.electricity_maps_co2_intensiteit"
]
},
"scheduler": {
"active": true,
"schedule": [
{
"time": "0432",
"action": "get_meteo_data"
},
{
"time": "1033",
"action": "get_meteo_data"
},
{
"time": "1634",
"action": "get_meteo_data"
},
{
"time": "0905",
"action": "train_ml_predictions"
},
{
"time": "2235",
"action": "get_meteo_data"
},
{
"time": "1256",
"action": "get_day_ahead_prices"
},
{
"time": "1354",
"action": "get_day_ahead_prices"
},
{
"time": "1456",
"action": "get_day_ahead_prices"
},
{
"time": "1554",
"action": "get_day_ahead_prices"
},
{
"time": "1650",
"action": "train_ml_predictions"
},
{
"time": "1656",
"action": "get_day_ahead_prices"
},
{
"time": "xx00",
"action": "calc_optimum"
},
{
"time": "xx15",
"action": "calc_optimum"
},
{
"time": "xx30",
"action": "calc_optimum"
},
{
"time": "xx45",
"action": "calc_optimum"
},
{
"time": "2359",
"action": "clean_data"
}
]
},
"meteoserver_attempts": 2
} |
:strip_exif()/f/image/Lpu2NU2HcD20P6iHe76z6BZY.png?f=user_large)
:strip_exif()/f/image/jl1Endh3pFZPZUZr8KhjhsvD.png?f=user_large)
:strip_exif()/f/image/MGUCOL2DtkOCba9AeVlS3V2s.png?f=user_large)
:strip_exif()/f/image/Ke3hpqQG62XXh7E1p4jSfdHu.png?f=user_large)
:strip_icc():strip_exif()/u/2145230/crop679ba1e673748_cropped.jpg?f=community)
:strip_exif()/f/image/u67AI8j44AdHgZO7Q1Rzaf9x.png?f=user_large)
Dagelijks zie ik wel positieve bedragen (bescheiden, maar toch..), zoals deze vandaag::strip_exif()/f/image/5sR1lY5cHLthUNfLwSKkfj3h.png?f=user_large)
:no_upscale():strip_icc():strip_exif()/f/image/5AvqvxJGhWrrv4KuwLqyY3W8.jpg?f=user_large)
:strip_exif()/f/image/PRaQW1PuJHaIAPGmuGfP38dU.png?f=user_large)
:strip_exif()/f/image/p4kKSh8HVJH4fMkjXftNYUww.png?f=user_large)
:strip_icc():strip_exif()/u/153524/crop56b4c089f1b16.jpeg?f=community)
:strip_exif()/f/image/bBvoU79GVtfG2gWPvgUGqt6N.png?f=user_large)
:strip_exif()/f/image/YZQ4Vju7mTfMAhF6CKc1upUn.png?f=user_large)
:strip_exif()/f/image/DhafQFuYDHT7sJZKtN8fkY8N.png?f=user_large)
:strip_exif()/f/image/P7il0C0t3cuCI5OJObjFDhwD.png?f=user_large)
:strip_exif()/u/5079/tweak.gif?f=community)
:strip_icc():strip_exif()/u/127354/crop60ad1df3adda4_cropped.jpg?f=community)
:strip_icc():strip_exif()/u/685142/crop66d0254153c6a_cropped.jpg?f=community)
:strip_exif()/f/image/het1fNLi36bl1z4xuxXNyo2i.png?f=user_large)
:strip_icc():strip_exif()/u/94573/crop5fb4d88a54f8e_cropped.jpeg?f=community)
:strip_exif()/f/image/OVSwsxgCTGPTzmnDl9NKRfnq.png?f=user_large)
:strip_exif()/u/159605/crop5bb7c558dfaa1.gif?f=community)
:strip_exif()/f/image/Jm1Q2eQzKNkwDxaYRYFvS9h5.png?f=user_large)
:strip_exif()/f/image/3d5ZxCWoaZEXheXXxXks88R6.png?f=user_large)
:no_upscale():strip_icc():strip_exif()/f/image/8rJn0vPWmhV3fxHbaW7GCfVj.jpg?f=user_large)
:strip_exif()/f/image/pVGzeCbNSMBdMZ0LquIxG4kV.png?f=user_large)
:strip_exif()/f/image/Mr7bkfzT9PMLTQYRB09IqTDD.png?f=user_large)
/u/55784/crop5aebfed47e17e.png?f=community)
:no_upscale():strip_icc():strip_exif()/f/image/S4VEMrc5D6Wby6x401aIx0YU.jpg?f=user_large)
:strip_exif()/f/image/ZkFohzlvb4JOHVLFZ44C5UCZ.png?f=user_large)
:strip_icc():strip_exif()/u/40490/avatar23.jpg?f=community){kind=avatar}
:strip_exif()/f/image/WUPhLe5HblbQAPXqzQSyRb4D.png?f=user_large)
:no_upscale():strip_icc():strip_exif()/f/image/1SmpWxuyIwCknrx81Zq4Fe1p.jpg?f=user_large)
:strip_exif()/f/image/7PHP0WB1NtCs4uZEECd1tVzP.png?f=user_large)
:strip_exif()/f/image/k7vrXkRR77CVUfrWAKbEeWQV.png?f=user_large)
/u/72057/crop686f7000b3c5b_cropped.png?f=community)
:strip_exif()/f/image/BuKAvKLygVyjM8a9cM9Z2WKw.png?f=user_large)
:strip_exif()/f/image/Ly0hsnsqffnQOsEcmxbcsBPG.png?f=user_large){kind=link}
:strip_exif()/f/image/lMfWWUjHEfchfeNTnahensil.png?f=user_large){kind=link}
