* Ecoforest / EPLucon – Scriptable widget (configurable)
*
* Data model:
* - statistics endpoint geeft een "rows table": veel meetregels met created_at + veel velden.
* - Wij nemen de LAATSTE row als "actueel".
*
* Aanpasbaar:
* - Zet velden aan/uit in TOGGLES (true/false).
* - Voeg eventueel eigen velden toe in FIELDS (label + mogelijke key-namen + unit + decimals).
*
*/
// =======================
// ✅ INSTELLINGEN
// =======================
const BASE = "https://portaal.eplucon.nl/api/v2";
const API_TOKEN = "";
const MODULE_ID = 1000640;
// Wanneer je in de Scriptable app runt, wil je een preview:
const PREVIEW_FAMILY = "medium"; // "small" | "medium" | "large"
// Velden aan/uit (standaard: DG1 temp + toerental aan)
const TOGGLES = {
dg1_temp: false,
compressor_rpm: true,
outside_temp: false,
indoor_temp: true,
ww_temp: true,
ww_mode: false,
cv_pressure: false,
power_now: false,
total_import_energy: false,
total_produced_energy: false,
brine_in: false,
brine_out: false,
brine_pressure: false,
heating_in: true,
heating_out: true,
condensation_temp: false,
evaporation_temp: false,
suction_gas_temp: false,
discharge_gas_temp: false,
superheat: false,
compressor_suction_pressure: false,
compressor_discharge_pressure: false,
valve_pos_sg2: false,
valve_pos_sg3: false,
valve_pos_sg4: false,
expansion_valve_pos: false,
fan_rpm: false,
setpoint_heating_dg1: false,
setpoint_cooling_dg1: false,
setpoint_heating_sg2: false,
setpoint_cooling_sg2: false,
setpoint_heating_sg3: false,
setpoint_cooling_sg3: false,
setpoint_heating_sg4: false,
setpoint_cooling_sg4: false,
overheat: false,
inverter_temp: false,
};
// =======================
// 📌 VELDDEFINITIES
// =======================
/**
* FIELDS definieert alle velden die je kunt tonen.
*
* id: moet overeenkomen met TOGGLES key
* label: wat je in de widget ziet
* keys: mogelijke veldnamen zoals ze in jouw row-object voorkomen
* unit: suffix (°C, bar, W, rpm, etc.)
* decimals: afronding
*
* Je kunt hier makkelijk velden bijmaken/aanpassen.
*/
const FIELDS = [
{ id: "dg1_temp", label: "Actuele temp DG1", keys: ["Actuele temp. DG1"], unit: "°C", decimals: 1 },
{ id: "compressor_rpm", label: "Compressor", keys: ["Compressor toerental"], unit: "rpm", decimals: 0 },
{ id: "outside_temp", label: "Buiten", keys: ["Buitentemp."], unit: "°C", decimals: 1 },
{ id: "indoor_temp", label: "Binnen", keys: ["Binnentemperatuur"], unit: "°C", decimals: 1 },
{ id: "ww_temp", label: "WW", keys: ["WW temperatuur"], unit: "°C", decimals: 1 },
{ id: "cv_pressure", label: "CV druk", keys: ["Cv druk", "CV druk"], unit: "bar", decimals: 1 },
{ id: "power_now", label: "Actueel verbruik", keys: ["Actueel verbruik"], unit: "W", decimals: 0 },
{ id: "total_import_energy", label: "Import energie", keys: ["Totaal import energie"], unit: "kWh", decimals: 1 },
{ id: "total_produced_energy", label: "Geproduceerd", keys: ["Totaal geproduceerde energie"], unit: "kWh", decimals: 1 },
{ id: "brine_in", label: "Brine in", keys: ["Brine in temperatuur"], unit: "°C", decimals: 1 },
{ id: "brine_out", label: "Brine uit", keys: ["Brine out temperatuur"], unit: "°C", decimals: 1 },
{ id: "brine_pressure", label: "Brine druk", keys: ["Brine druk"], unit: "bar", decimals: 1 },
{ id: "heating_in", label: "Heating in", keys: ["Heating in temperatuur"], unit: "°C", decimals: 1 },
{ id: "heating_out", label: "Heating out", keys: ["Heating out temperatuur"], unit: "°C", decimals: 1 },
{ id: "condensation_temp", label: "Condensatie", keys: ["Condensatie temp."], unit: "°C", decimals: 1 },
{ id: "evaporation_temp", label: "Verdamping", keys: ["Verdamping temp."], unit: "°C", decimals: 1 },
{ id: "suction_gas_temp", label: "Zuig gas", keys: ["Zuig gas temperatuur"], unit: "°C", decimals: 1 },
{ id: "discharge_gas_temp", label: "Pers gas", keys: ["Pers gas temperatuur"], unit: "°C", decimals: 1 },
{ id: "superheat", label: "Oververhitting", keys: ["Oververhitting"], unit: "K", decimals: 1 },
{ id: "compressor_suction_pressure", label: "Zuigdruk", keys: ["Compressorzuigdruk"], unit: "bar", decimals: 1 },
{ id: "compressor_discharge_pressure", label: "Afvoerdruk", keys: ["Compressorafvoerdruk"], unit: "bar", decimals: 1 },
{ id: "valve_pos_sg2", label: "Ventiel SG2", keys: ["Positie ventiel SG2"], unit: "%", decimals: 0 },
{ id: "valve_pos_sg3", label: "Ventiel SG3", keys: ["Positie ventiel SG3"], unit: "%", decimals: 0 },
{ id: "valve_pos_sg4", label: "Ventiel SG4", keys: ["Positie ventiel SG4"], unit: "%", decimals: 0 },
{ id: "expansion_valve_pos", label: "Exp. ventiel", keys: ["Positie expansie ventiel"], unit: "%", decimals: 0 },
{ id: "fan_rpm", label: "Ventilator", keys: ["Act. vent. toerental"], unit: "rpm", decimals: 0 },
{ id: "setpoint_heating_dg1", label: "SP verw DG1", keys: ["Setpoint verwarming DG1"], unit: "°C", decimals: 1 },
{ id: "setpoint_cooling_dg1", label: "SP koel DG1", keys: ["Setpoint koeling DG1"], unit: "°C", decimals: 1 },
{ id: "setpoint_heating_sg2", label: "SP verw SG2", keys: ["Setpoint verwarming SG2"], unit: "°C", decimals: 1 },
{ id: "setpoint_cooling_sg2", label: "SP koel SG2", keys: ["Setpoint koeling SG2"], unit: "°C", decimals: 1 },
{ id: "setpoint_heating_sg3", label: "SP verw SG3", keys: ["Setpoint verwarming SG3"], unit: "°C", decimals: 1 },
{ id: "setpoint_cooling_sg3", label: "SP koel SG3", keys: ["Setpoint koeling SG3"], unit: "°C", decimals: 1 },
{ id: "setpoint_heating_sg4", label: "SP verw SG4", keys: ["Setpoint verwarming SG4"], unit: "°C", decimals: 1 },
{ id: "setpoint_cooling_sg4", label: "SP koel SG4", keys: ["Setpoint koeling SG4"], unit: "°C", decimals: 1 },
{ id: "overheat", label: "Oververhitting", keys: ["Oververhitting"], unit: "K", decimals: 1 },
{ id: "inverter_temp", label: "Inverter temp", keys: ["Inverter temperatuur"], unit: "°C", decimals: 1 },
{ id: "ww_mode", label: "WW", keys: ["WW"], unit: "", decimals: 0 },
];
// =======================
// 🔧 HELPERS
// =======================
async function showInAppOrWidget(widget, family = "medium") {
if (config.runsInWidget) {
Script.setWidget(widget);
} else {
if (family === "small") await widget.presentSmall();
else if (family === "large") await widget.presentLarge();
else await widget.presentMedium();
}
Script.complete();
}
// EPLucon lijkt invalid values te gebruiken zoals -9999.
function cleanValue(v) {
if (v === null || v === undefined) return null;
const num = Number(v);
if (!Number.isNaN(num) && (num === -9999 || num === 9999)) return null;
return v;
}
function fmtValue(v, unit, decimals) {
v = cleanValue(v);
if (v === null || v === undefined) return "—";
const num = Number(v);
if (Number.isNaN(num)) return String(v) + (unit ? ` ${unit}` : "");
return num.toFixed(decimals) + (unit ? ` ${unit}` : "");
}
async function apiGetJSON(path) {
const req = new Request(`${BASE}${path}`);
req.method = "GET";
req.headers = { "Authorization": `Bearer ${API_TOKEN}`, "Accept": "application/json" };
req.timeoutInterval = 6;
return await req.loadJSON();
}
/**
* - stats.data is niet de rows-array maar bevat zelf weer .data
* Daarom unwrapen totdat we een array vinden.
*/
function extractRows(stats) {
if (Array.isArray(stats)) return stats;
const candidates = [
stats?.data,
stats?.data?.data,
stats?.result?.data,
stats?.items,
stats?.items?.data,
];
for (const c of candidates) if (Array.isArray(c)) return c;
// follow .data chain (max 5)
let cur = stats;
for (let i = 0; i < 5; i++) {
if (Array.isArray(cur)) return cur;
if (cur && typeof cur === "object" && cur.data !== undefined) cur = cur.data;
else break;
}
return null;
}
async function fetchRowsToday(moduleId) {
const now = new Date();
const year = now.getFullYear();
const month = now.getMonth() + 1;
const path = `/econtrol/modules/${moduleId}/statistics`
const stats = await apiGetJSON(path);
const rows = extractRows(stats);
console.log(rows[rows.length-1])
if (!Array.isArray(rows)) {
const topKeys = stats && typeof stats === "object" ? Object.keys(stats).join(",") : String(typeof stats);
throw new Error("Kan rows-array niet vinden. Top-level keys: " + topKeys);
}
if (rows.length === 0) throw new Error("Geen rows vandaag (array leeg).");
return rows;
}
function getLatestRow(rows) {
return rows[rows.length - 1];
}
function getField(row, keys) {
for (const k of keys) {
if (row[k] !== undefined) return row[k];
}
return null;
}
// =======================
// 🖼️ WIDGET UI
// =======================
function buildWidgetFromRow(row) {
const w = new ListWidget();
w.setPadding(20, 20, 20, 20);
const title = w.addText("Ecoforest live");
title.font = Font.boldSystemFont(16);
w.addSpacer(8);
// 1) Bepaal welke FIELDS aan staan
const active = FIELDS.filter(f => TOGGLES[f.id]);
// 2) Render ze
for (const f of active) {
const raw = getField(row, f.keys);
const text = fmtValue(raw, f.unit, f.decimals);
const t = w.addText(`${f.label}: ${text}`);
t.font = Font.systemFont(18);
t.minimumScaleFactor = 0.7;
}
w.addSpacer(8);
const ts = row["created_at"] ? new Date(row["created_at"]) : new Date();
const footer = w.addText(
`Laatste meting: ${ts.toLocaleTimeString("nl-NL", { hour: "2-digit", minute: "2-digit" })}`
);
footer.font = Font.systemFont(10);
footer.textOpacity = 0.6;
return w;
}
// =======================
// ▶️ MAIN
// =======================
try {
const moduleId = MODULE_ID;
const rows = await fetchRowsToday(moduleId);
const latest = getLatestRow(rows);
const widget = buildWidgetFromRow(latest);
await showInAppOrWidget(widget, PREVIEW_FAMILY);
} catch (e) {
const w = new ListWidget();
w.setPadding(12, 12, 12, 12);
w.addText("Ecoforest live").font = Font.boldSystemFont(16);
w.addSpacer(8);
w.addText("Fout bij ophalen").font = Font.boldSystemFont(14);
w.addSpacer(4);
w.addText(String(e)).font = Font.systemFont(11);
await showInAppOrWidget(w, PREVIEW_FAMILY);
} |
:strip_icc():strip_exif()/u/287999/profile-image-display.jspa.jpg?f=community)
:
En mooi actueel: "API BUS Client manual 03E (Rev1)/2025"
:strip_exif()/f/image/YTcEOkLZke85N2wJ8IEABJ3a.png?f=user_large)
:strip_icc():strip_exif()/u/247955/crop67a0b8f856d16_cropped.jpg?f=community)
:strip_icc():strip_exif()/u/868785/crop630112412b302.jpg?f=community)
:strip_exif()/u/72870/crop5db2a0081b965.gif?f=community)
/u/366211/crop633ace019e8da_cropped.png?f=community)
- waar je wel overzichtelijk en in detail kan volgen zal me wel in staat stellen om in de instellingen te gaan finetunen.
![[Afbeelding]](https://tweakers.net/i/FWLl39f583xRFA62HLWIqUJ8cJQ=/fit-in/4000x4000/filters:no_upscale():gifsicle():strip_exif()/f/image/2NxMc7DwCrZRVS6yWfgQ7Mrn.gif?f=user_large){kind=link}
