"homeassistant": { },
"database ha": {
"password": "!secret db_ha_password"
},
"database da": {
"engine": "mysql",
"database": "day_ahead",
"username": "day_ahead",
"password": "!secret db_da_password"
},
"meteoserver-key": "!secret meteoserver-key",
"prices": {
"source day ahead": "nordpool",
"regular high": 0.30,
"regular low": 0.20,
"switch to low": 23,
"energy taxes consumption": {
"2022-01-01": 0.06729,
"2023-01-01": 0.12599,
"2024-01-01": 0.10880,
"2025-01-01": 0.10154,
"2026-01-01": 0.09161
},
"energy taxes production": {
"2022-01-01": 0.06729,
"2023-01-01": 0.12599,
"2024-01-01": 0.10880,
"2025-01-01": 0.10154,
"2026-01-01": 0.09161
},
"cost supplier consumption": {
"2022-01-01": 0.0200
},
"cost supplier production": {
"2022-01-01": 0.0200
},
"vat consumption": {
"2022-01-01": 21,
"2022-07-01": 9,
"2023-01-01": 21
},
"vat production": {
"2022-01-01": 21,
"2022-07-01": 9,
"2023-01-01": 21
},
"last invoice": "2026-01-26",
"tax refund": "True"
},
"logging level" : "info",
"use_calc_baseload": "true",
"baseload calc periode": 56,
"baseload": [
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35,
0.35
],
"graphical backend": "",
"graphics": {
"style": "Solarize_Light2",
"show" : "true",
"battery balance": "True",
"prices consumption": "True",
"prices production": "False",
"prices spot": "True",
"average consumption": "True"
},
"strategy": "minimize cost",
"notifications": {
},
"grid": {
"max_power": 17
},
"history": {
"save days": 7
},
"dashboard": {
"port": 5000
},
"boiler": {
"boiler present": "False",
"entity actual temp.": "sensor.boiler_gemeten",
"entity setpoint": "sensor.boiler_ingesteld",
"entity hysterese": "sensor.hysterese_hot_water",
"cop": 2.9,
"cooling rate": 0.4,
"volume": 180,
"heating allowed below": 44,
"elec. power": 1500,
"activate service": "press",
"activate entity": "input_button.hw_trigger"
},
"heating": {
"heater present": "False",
"degree days factor": 3.6,
"stages": [
{
"max_power": 225,
"cop": 7.1
},
{
"max_power": 300,
"cop": 7.0
},
{
"max_power": 400,
"cop": 6.5
},
{
"max_power": 500,
"cop": 6.0
},
{
"max_power": 600,
"cop": 5.5
},
{
"max_power": 750,
"cop": 5.0
},
{
"max_power": 1000,
"cop": 4.5
},
{
"max_power": 1250,
"cop": 4.0
}
],
"entity adjust heating curve": "input_number.stooklijn_verschuiving_day_ahead",
"adjustment factor": 0.04
},
"battery": [
{
"name": "Marstek Venus-E",
"entity actual level": "sensor.marstek_m1_battery_state_of_charge",
"capacity": 5.12,
"lower limit": 20,
"upper limit": 100,
"optimal lower level": 11,
"entity min soc end opt": "input_number.marstek_m1_discharging_cutoff_capacity",
"entity max soc end opt": "input_number.marstek_m1_charging_cutoff_capacity",
"charge stages": [
{ "power": 0.0, "efficiency": 1.0 },
{ "power": 100, "efficiency": 0.5 },
{ "power": 250, "efficiency": 0.5836 },
{ "power": 500, "efficiency": 0.7229 },
{ "power": 800, "efficiency": 0.89 },
{ "power": 1000, "efficiency": 0.8722 }
],
"discharge stages": [
{ "power": 0.0, "efficiency": 1.0 },
{ "power": 100, "efficiency": 0.5 },
{ "power": 250, "efficiency": 0.5836 },
{ "power": 500, "efficiency": 0.7229 },
{ "power": 800, "efficiency": 0.89 },
{ "power": 1000, "efficiency": 0.8722 },
{ "power": 1250, "efficiency": 0.85 },
{ "power": 2500, "efficiency": 0.86 }
],
"dc_to_bat efficiency": 0.98,
"bat_to_dc efficiency": 0.98,
"cycle cost": 0.054,
"minimum power": 4,
"entity set power feedin": "input_number.dao_marstek_power_feedin",
"entity set operating mode": "input_select.dao_marstek_operating_mode",
"entity stop inverter": "input_datetime.dao_marstek_stop_inverter",
"entity balance switch": "input_boolean.dao_marstek_balance_switch",
"solar": []
},
{
"name": "Nexus",
"entity actual level": "sensor.solis_s6_eh3p10k_h_zp_battery_soc",
"capacity": 20,
"lower limit": 7,
"upper limit": 100,
"optimal lower level": 7,
"charge stages": [
{ "power": 0, "efficiency": 0.50 },
{ "power": 50, "efficiency": 0.54 },
{ "power": 100, "efficiency": 0.58 },
{ "power": 150, "efficiency": 0.62 },
{ "power": 200, "efficiency": 0.66 },
{ "power": 250, "efficiency": 0.70 },
{ "power": 300, "efficiency": 0.74 },
{ "power": 350, "efficiency": 0.78 },
{ "power": 400, "efficiency": 0.82 },
{ "power": 450, "efficiency": 0.86 },
{ "power": 500, "efficiency": 0.90 },
{ "power": 550, "efficiency": 0.905 },
{ "power": 600, "efficiency": 0.91 },
{ "power": 650, "efficiency": 0.915 },
{ "power": 700, "efficiency": 0.92 },
{ "power": 750, "efficiency": 0.925 },
{ "power": 800, "efficiency": 0.93 },
{ "power": 850, "efficiency": 0.935 },
{ "power": 900, "efficiency": 0.94 },
{ "power": 950, "efficiency": 0.945 },
{ "power": 1000, "efficiency": 0.95 },
{ "power": 1050, "efficiency": 0.951 },
{ "power": 1100, "efficiency": 0.952 },
{ "power": 1150, "efficiency": 0.953 },
{ "power": 1200, "efficiency": 0.954 },
{ "power": 1250, "efficiency": 0.955 },
{ "power": 1300, "efficiency": 0.956 },
{ "power": 1350, "efficiency": 0.957 },
{ "power": 1400, "efficiency": 0.958 },
{ "power": 1450, "efficiency": 0.959 },
{ "power": 1500, "efficiency": 0.96 },
{ "power": 1550, "efficiency": 0.961 },
{ "power": 1600, "efficiency": 0.962 },
{ "power": 1650, "efficiency": 0.963 },
{ "power": 1700, "efficiency": 0.964 },
{ "power": 1750, "efficiency": 0.965 },
{ "power": 1800, "efficiency": 0.966 },
{ "power": 1850, "efficiency": 0.967 },
{ "power": 1900, "efficiency": 0.968 },
{ "power": 1950, "efficiency": 0.969 },
{ "power": 2000, "efficiency": 0.97 },
{ "power": 2500, "efficiency": 0.9704 },
{ "power": 3000, "efficiency": 0.9708 },
{ "power": 3500, "efficiency": 0.9712 },
{ "power": 4000, "efficiency": 0.9716 },
{ "power": 4500, "efficiency": 0.972 },
{ "power": 5000, "efficiency": 0.975 },
{ "power": 5500, "efficiency": 0.975 },
{ "power": 6000, "efficiency": 0.975 },
{ "power": 6500, "efficiency": 0.975 },
{ "power": 7000, "efficiency": 0.975 },
{ "power": 7500, "efficiency": 0.975 },
{ "power": 8000, "efficiency": 0.975 },
{ "power": 8500, "efficiency": 0.975 },
{ "power": 9000, "efficiency": 0.975 },
{ "power": 9500, "efficiency": 0.975 },
{ "power": 10000, "efficiency": 0.975 }
],
"discharge stages": [
{ "power": 0, "efficiency": 0.50 },
{ "power": 50, "efficiency": 0.54 },
{ "power": 100, "efficiency": 0.58 },
{ "power": 150, "efficiency": 0.62 },
{ "power": 200, "efficiency": 0.66 },
{ "power": 250, "efficiency": 0.70 },
{ "power": 300, "efficiency": 0.74 },
{ "power": 350, "efficiency": 0.78 },
{ "power": 400, "efficiency": 0.82 },
{ "power": 450, "efficiency": 0.86 },
{ "power": 500, "efficiency": 0.90 },
{ "power": 550, "efficiency": 0.905 },
{ "power": 600, "efficiency": 0.91 },
{ "power": 650, "efficiency": 0.915 },
{ "power": 700, "efficiency": 0.92 },
{ "power": 750, "efficiency": 0.925 },
{ "power": 800, "efficiency": 0.93 },
{ "power": 850, "efficiency": 0.935 },
{ "power": 900, "efficiency": 0.94 },
{ "power": 950, "efficiency": 0.945 },
{ "power": 1000, "efficiency": 0.95 },
{ "power": 1050, "efficiency": 0.951 },
{ "power": 1100, "efficiency": 0.952 },
{ "power": 1150, "efficiency": 0.953 },
{ "power": 1200, "efficiency": 0.954 },
{ "power": 1250, "efficiency": 0.955 },
{ "power": 1300, "efficiency": 0.956 },
{ "power": 1350, "efficiency": 0.957 },
{ "power": 1400, "efficiency": 0.958 },
{ "power": 1450, "efficiency": 0.959 },
{ "power": 1500, "efficiency": 0.96 },
{ "power": 1550, "efficiency": 0.961 },
{ "power": 1600, "efficiency": 0.962 },
{ "power": 1650, "efficiency": 0.963 },
{ "power": 1700, "efficiency": 0.964 },
{ "power": 1750, "efficiency": 0.965 },
{ "power": 1800, "efficiency": 0.966 },
{ "power": 1850, "efficiency": 0.967 },
{ "power": 1900, "efficiency": 0.968 },
{ "power": 1950, "efficiency": 0.969 },
{ "power": 2000, "efficiency": 0.97 },
{ "power": 2500, "efficiency": 0.9704 },
{ "power": 3000, "efficiency": 0.9708 },
{ "power": 3500, "efficiency": 0.9712 },
{ "power": 4000, "efficiency": 0.9716 },
{ "power": 4500, "efficiency": 0.972 },
{ "power": 5000, "efficiency": 0.975 },
{ "power": 5500, "efficiency": 0.975 },
{ "power": 6000, "efficiency": 0.975 },
{ "power": 6500, "efficiency": 0.975 },
{ "power": 7000, "efficiency": 0.975 },
{ "power": 7500, "efficiency": 0.975 },
{ "power": 8000, "efficiency": 0.975 },
{ "power": 8500, "efficiency": 0.975 },
{ "power": 9000, "efficiency": 0.975 },
{ "power": 9500, "efficiency": 0.975 },
{ "power": 10000, "efficiency": 0.975 }
],
"dc_to_bat efficiency": 0.98,
"bat_to_dc efficiency": 0.98,
"cycle cost": 0,
"minimum power": 50,
"entity set power feedin": "input_number.dao_nexus_power_feedin",
"entity set operating mode": "input_select.dao_nexus_operating_mode",
"entity stop inverter": "input_datetime.dao_nexus_stop_inverter",
"entity balance switch": "input_boolean.dao_nexus_balance_switch",
"solar": []
}
],
"solar": [
{
"name": "Enphase",
"entity pv switch": "",
"ml_prediction": "true",
"entities sensors": "sensor.envoy_122207077148_lifetime_energy_production",
"strings": [
{ "tilt": 15, "orientation": 135, "capacity": 4.8, "yield": 0.0125 },
{ "tilt": 15, "orientation": 0, "capacity": 1.68, "yield": 0.0125 },
{ "tilt": 15, "orientation": 135, "capacity": 1.62, "yield": 0.0125 }
]
}
],
"electric vehicle": [
{
"name": "Skoda",
"capacity": 54,
"entity position": "device_tracker.skoda_enyaq_positie",
"entity actual level": "sensor.skoda_enyaq_accupercentage",
"entity plugged in": "binary_sensor.skoda_enyaq_laadkabel",
"charge stages": [
{ "ampere": 0, "efficiency": 0},
{ "ampere": 16, "efficiency": 1}
],
"charge three phase": "true",
"charge scheduler": {
"entity set level": "input_number.dao_enyaq_target_soc",
"level margin": 4,
"entity ready datetime": "input_datetime.dao_enyaq_charged_at"
},
"charge switch": "input_boolean.dao_enyaq_charge_switch",
"entity set charging ampere": "input_number.dao_enyaq_charge_ampere"
}],
"machines" : [ ],
"tibber": {
"api_token": "!secret tibber_api_token"
},
"report": {
"entities grid consumption": [
"sensor.stroommeter_total_power_import_t1",
"sensor.stroommeter_total_power_import_t2"
],
"entities grid production": [
"sensor.stroommeter_total_power_export_t1",
"sensor.stroommeter_total_power_export_t2"
],
"entities solar production ac": [
"sensor.envoy_122207077148_lifetime_energy_production"
],
"entities solar production dc": [],
"entities ev consumption" : ["sensor.myenergi_zappi_21266984_energy_used_today"],
"entities wp consumption" : ["sensor.aircos_energy_import"],
"entities boiler consumption": ["sensor.bedden_energy_import"],
"entities machine consumption": [
"sensor.wasmachine_totale_energie_import",
"sensor.droger_totale_energie_import",
"sensor.vaatwasser_totale_energie_import"
],
"entities battery consumption": [
"sensor.marstek_m1_daily_charging_energy",
"sensor.solis_s6_eh3p10k_h_zp_today_battery_charge_energy"
],
"entities battery production": [
"sensor.marstek_m1_daily_discharging_energy",
"sensor.solis_s6_eh3p10k_h_zp_today_battery_discharge_energy"
],
"entity co2-intensity": ["sensor.co2_signal_co2_intensiteit"]
},
"scheduler": {
"active": "true",
"0430": "get_meteo_data",
"1030": "get_meteo_data",
"1630": "get_meteo_data",
"2230": "get_meteo_data",
"1255": "get_day_ahead_prices",
"1355": "get_day_ahead_prices",
"1455": "get_day_ahead_prices",
"1554": "get_day_ahead_prices",
"1655": "get_day_ahead_prices",
"xx00": "calc_optimum",
"2359": "clean_data"
}
} |
/u/528703/crop565b8adf732d6_cropped.png?f=community)
:strip_icc():strip_exif()/u/127354/crop60ad1df3adda4_cropped.jpg?f=community)
. Erg tevreden!:no_upscale():strip_icc():strip_exif()/f/image/oX3qw2MhPLGMFNcwnnPrsza0.jpg?f=user_large)
:strip_icc():strip_exif()/u/96319/crop660584d0826a8_cropped.jpg?f=community)
.
:strip_exif()/f/image/xpBDiiiXUjXwZYs87hZQ0bq4.png?f=user_large)
:strip_exif()/f/image/NLiyECL5HdUXuIVHA0iekHrS.png?f=user_large)
:no_upscale():strip_icc():strip_exif()/f/image/r52ufoIoCL4kSM7L9SYvywn7.jpg?f=user_large)
:no_upscale():strip_icc():strip_exif()/f/image/fSCI0nt1kzGSJYOHk51eMVew.jpg?f=user_large)
! Ben je bereid de yamls te delen? 2e grafiek (met soc historie en prognose) kan waarschijnlijk ook helpen om afwijkende efficientie op te sporen en de configuratie te verbeteren.
:strip_exif()/f/image/tcZTkhDV9QRJIuAJZghEEaWn.png?f=user_large)
:strip_exif()/f/image/fK2ivW9a8bs7WlwNZYTkgSGY.png?f=user_large)
:no_upscale():strip_icc():strip_exif()/f/image/ogoWN5xIQJQJdR82sE7Qn77Y.jpg?f=user_large)
:strip_exif()/f/image/lHNqgrZepKnJnQm14c1IIjQf.png?f=user_large)
:strip_exif()/f/image/WTNMXvr6w7AwXo3aEb1f6UQS.png?f=user_large)
:strip_exif()/f/image/qmIPqSuOrkgkKu1zIGZkEOIN.png?f=user_large)
:strip_exif()/f/image/s9vSdkrfW7fwYpdzqzjdlS0B.png?f=user_large)
:strip_icc():strip_exif()/u/2026/DSC_2281.jpg?f=community)
:strip_icc():strip_exif()/u/685142/crop66d0254153c6a_cropped.jpg?f=community)
:strip_exif()/f/image/bSPFfHiRWyLdXhFGSKOjZLUx.png?f=user_large)
