Ik zal bij deze eens even de system specs posten voor de M17XR4
System Specifications
Processors
Processor type Intel® Core™ i7
Intel® Core™ i7-3820QM - 2.7 GHz - 45W (Ivy Bridge)
Intel® Core™ i7-3720QM - 2.6 GHz (Ivy Bridge)
Intel® Core™ i7-3610QM - 2.3 GHz (Ivy Bridge)
Intel® Core™ i7-2670QM - 2.2 GHz (SandyBridge)
Level 3 (L3) cache upto 8 MB
System Information
System chipset Mobile Intel HM77 Express Chipset
SDRAM bus width one or two 64-bit channels of DDR3 memory up to 1600 MHz
Processor data width 64 bits
Processor address bus width 32 bits
BIOS SPI Flash Memory 32 Mbit
Graphics bus PCIe x16 Gen2 and Gen3
PCI bus 32 Bits
Memory
Memory module connectors four internally-accessible DDR3 using JEDEC SODIMM
sockets
Memory module capacities 2 GB, 4 GB, and 8 GB
Memory type up to 1600 MHz, unbuffered non-ECC, single-channel and dual-channel DDR3 configuration
Memory configurations
possible 4 GB, 6 GB, 8 GB, 12 GB, 16 GB, 24 GB and 32 GB
9-in-1 Media Card Reader
9-in-1 media memory card controller Realtek PCIE Card Reader
Cards supported Secure Digital (SD) memory card
Secure Digital Input/Output (SDIO) card
Secure Digital Extended Capacity (SDXC) card
MultiMedia Card (MMC)
MultiMedia Card plus (MMC+)
Memory Stick PRO
xD-Picture Card (type - M and type - H)
Hi Density-SD (SDHD)
Hi Capacity-SD (SDHC)
Connectors
Audio •one stereo headphones/speakers port
•one microphone/speakers port
•one headphones/microphone/speakers combo port
Network adapter RJ-45 port 10/100/1000
USB 4 x 9-pin USB 3.0-compliant ports
eSATA/USB combo 1 x 7-pin/4-pin eSATA/USB 2.0-compliant combo port with PowerShare and Windows debugging
VGA 15-pin connector
HDMI •Input : one 19-pin connector
•Output : one 19-pin connector
Mini Display Port one 20-pin connector
Communications
Network adapter 10/100/1000 Mbps Ethernet LAN on system board
Wireless one half Mini-Card slot
one full Mini-Card slot
Bluetooth; Wireless Display (optional); WirelessHD
(optional)
Video
Video controller Integrated - Intel HD Graphics 3000/ Intel HD Graphics 4000
Discrete - NVIDIA GeForce GTX 660M / NVIDIA GeForce GTX 675M/ AMD Radeon HD 7970M
External display support HDMI 1.4, Mini DisplayPort 1.2, and Intel Wireless Display (optional))
Video Memory Integrated - 512 MB dedicated video memory (for total system memory greater than 4 GB)
Discrete - 2.0 GB
Audio
Audio type High-Definition 5.1 surround sound audio
Audio Controller Creative Sound Blaster Recon3Di High-Definition Audio controller
Speaker dual 8-ohms speakers in both the left and right speaker
assembly
Internal speaker amplifier up to 5 W per channel; up to 10 W total power
Internal microphone support dual digital microphone in camera assembly
Volume controls program menus and keyboard media function keys
Media [Optical Drive]
Interface SATA
Type Slot drive
Drives supported SATA-compliant Blu-ray Disc combo or DVD+/-RW
Display
Type 17.3-inch FHD+ WLED
17.3-inch FHD TL 120 Hz WLED with NVIDIA 3D vision support
17.3-inch HD+ WLED
Refresh Rate 60 Hz
Operating angle 0° (closed) to 140°
Maximum resolution 1920 x 1080
Pixel pitch 0.2550 mm
Controls Brightness can be controlled through keyboard shortcuts
Keyboard (backlit)
Number of keys 101 (Korea, U.S., and Canada); 102 (Europe); 104 (Japan)
Layout QWERTY/AZERTY/Kanji
Backlight color RGB; colors can be changed by invoking the AlienFX
application in the Alienware Command Center.
Camera
Pixel 2.1 megapixel SkypeHD-certified
Video resolution 1920 x 1080
Diagonal viewing angle 66 degrees
Touch Pad
X/Y position resolution
(graphics table mode) 240 CPI
Size
Width 54.00 mm (2.13 inches) sensor-active area
Height 100.00 mm (3.94 inches) rectangle
Battery
Type 9-cell “smart” lithium ion (90 Whr)
Dimensions
Depth 90.00 mm (3.54 inches)
Height 22.00 mm (0.87 inches)
Width 233.00 mm (9.17 inches)
Weight 0.52 kg (1.14 lb)
Voltage 11.1 VDC
Charge time (approximate)
Computer off 4 hours (100%)
2 hours (80%)
Operating time Approximately 2.5 hours battery life, if the computer is working in the UMA Graphics Mode with high performance discrete GFX cards disabled. Press to switch between integrated graphics and discrete graphics.
NOTE:
Battery operating time varies depending on operating conditions and can be significantly reduced under certain power-intensive conditions.
Life span (approximate) 300 discharge/charge cycles
Temperature range
Operating 0° to 50° C (32° to 122° F)
Storage –20° to 60°C (–4° to 140°F)
Coin-cell battery CR-2032
AC Adapter
240 W
Input voltage 100-240 VAC
Input current (max) 150 W
Input frequency 50–60 Hz
Output current 240 W
Output power 240 W
Rated output voltage 19.5 VDC
Temperature range
Operating 0° to 40° C (32° to 104° F)
Storage –40° to 70°C (–40° to 158°F)
Connector types
DC connector 3 pin, 7.4 mm plug
AC connector 3 pin - C13
Physical
Height 44.5 mm to 45.0 mm (1.75 inches to 1.77 inches) - Front to Back
Width 410.0 mm (16.14 inches)
Depth 304.3 mm (11.98 inches)
Weight with 9-cell battery and optical drive (starting at) 4.26 kg (9.40 lb)
NOTE:
The weight of your notebook will vary depending on the configuration ordered and the manufacturing variability.
Environmental
Temperature range
Operating 0° to 35° C (32° to 95° F)
Storage –40° to 65° C (–40° to 149° F)
Relative humidity
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
Maximum vibration (using a random-vibration
spectrum that simulates user environment)
Operating 0.66 GRMS
Storage 1.30 GRMS
Maximum shock (measured with hard drive in
head-parked position and a 2-ms half-sine pulse)
Operating 110 G
Storage 160 G
Altitude
Operating –15.2 to 3048 m (–50 to 10,000 ft)
Storage –15.2 to 10,668 m (–50 to 35,000 ft)
Airborne contaminant level G2 or lower as defined by ISA-S71.04-1985
